Dewatering screen panel or screen plate or sieve bend screen or acr screen plate

Feiya International Group Ltd Anping Branch Factory---Xinlu Wire Mesh Products Co.,ltd EFFLUENT SCREENING SYSTEMS

Feiya International Group Ltd Anping Branch Factory---Xinlu Wire Mesh Products Co.,ltd Screens offer Effluent Screening Systems. We utilize a cylindrical drum constructed of wedge wire screen to remove solid materials from waste streams at capacities from 200 to 4,650 gal/min. (757 to 17,600 liter/min.). Effluent discharges from a head box, overflows a dam and flows onto the outside of the rotating cylinder, allowing water to pass through the wedge wire into the cylinder. A doctor blade scrapes sludge and debris collected on the outside of the cylinder, while an internal spray line dislodges particles blinding the screen.

TYPICAL APPLICATIONS

· Rendering plants to separate sludge

· Plastic extrusions cooling bath water to separate pellets

· Municipal wastewater sludge removal

· Pulp and paper sludge removal

· Separation of solids from any slurry in high volumes

Theses variable speed machines are equipped with wedge wire screen in a range of seven orifice sizes from .010 to .100 in. (.25 to 2.54 mm).

For assistance in selecting the proper type, size and configuration of equipment for your specific need, please contact us.

Dewatering screen panel or screen plate or sieve bend screen or acr screen plate Images
